GPS Features: - Built-in compass GPS module - Main chip: 6M - With fast satellite searching speed and high precision - Compatible with APM serial port and I2C port - Includes round plastic shell
- Pre-configured, Flashed with the correct settings, and tested - Super Bright LED,BlackPlane with Standard Mk style mounting holes 45mm X 45mm - Cable included - With L5883 compass Cable length in 25CM - Dimensions: 53.5*53.5*15.5 - Weight: 30g
Description: C/A code,1.023MHz Receiver Frequency:L1 [1575.42MHz] Locate performance 2D :3m(Average) 2D:2m(average),with WAAS drifting<0.02m> accuracy:1us coordinate system:WGS84 max attitude height:18000 Max speed:515m/s
Specification: tracking sensitivity:161dBm Capture sensitivity:148dBm cold start time:38s average Warm start time:35s average hot start time:1s average Capture time:0.1s Average Temperature:40 centi grade to +80 centi grade wide power supply voltage:+3.5V~+5.5V
1 Size: 183*193*100mm
2 Weight: 0.88kg
3 Frequency: 2.4GHz ISM band (2400MHz to 2485MHz)
4 Modulation mode: QPSK
5 Channel bandwidth: 5.0MHz
6 Spread spectrum: DSSS
7 Adjacent channel rejection: >38dbm
8 Transmitter power: <100mW(PCB testing), <20dbm(3 meter air testing)
9 Operating Current: <105mA
10 Operating Voltage: 7.4~15V
11 Control distance: more than 900 meters ground, 1.5kms air
12 Channel: 9 channels, 5~9 channels are customizable
13 Simulator model: under the simulator model the transmitter action turn off, change to power saving model
14 Screen: 2.8 inches 16 colorful screen , 240*320 pixels
15 Compatible model: Include all 120 degree and 90 degree swashplate helicopter, all fix wing and glider, five flying model and aircraft
Features
FULL TYPES AND FUNCTIONS
Suit for all airplanes including helicopter 8 swash plate models, fixed wing 2 airfoils 3 rears,
gliders 4 airfoils 2 rears and aircraft.
FAST RESPONSE
It takes 3ms only for 9 channels to response parallel, which is less than the average time 20ms.
SUPER STABLE AND LONG DISTANCE OPERATING
DSSS spread spectrum mode supplies better performance in anti-interference .
QPSK modulation mode.
Actual measurement: 900 meters ground and 1.5kms air.
