Specifications：
Brand: GEPRC
Item Name：GEP-Mark4 HD7
Frame Type：H-TYPE
Propeller : 7 Inch
Wheelbase：295mm
Size：193*223mm
Mounting Holes: 30.5*30.5mm/20*20mm
Weight：140g
Arms Plate : 5mm
Side Plate : 2.5mm
Top plate : 2.5mm
Bottom plate : 2.5mm
Protect plate : 2mm
Product name: GEP-Mark4 HD5
Frame type: H type
paddle: 5inch
Wheelbase: 224mm
Size: 138*176mm
Weight: 121g
Floor thickness: 2.5mm
Top plate thickness: 2.5mm
Side board thickness: 2.5mm
Splint thickness: 2mm
Thickness of front and rear protective frame: 2mm
Arm thickness: 5mm
Features：
1. 3D printing parts are fixed and protected
2. No propeller in the view
3. Full 3K Carbon Fiber Frame
4. Super lightweight Freestyle frame
5. Beautiful appearance design，durable in crashing
6. Quick maintenance Arms and replacement of equipment
7. 25mm standoffs for better height and CG relation,Ample space for electronic installation
8. ALU6061 Srandoff New , Strengthen the hardness
9. There are 30.5*30.5mm and 20*20mm control holes , Stack can fit in the center or the rear.
10. High quality 3K twill carbon fiber plate, high precision CNC processing
11. YFS screw, 12.9 grade strength, non-slip, anti-rust,Durable steel hardware
Package Include:GEP-Mark4 HD7/GEP-Mark4 HD5(Optional)
4 x 5mm 5inch Arms Plate
2 x 2.5mm Side Plate
1 x 2.5mm Top Plate
1 x 2.5mm Bottom Plate
2 x 2mm Bumpers Plate
2 x 2mm Reinforce Plate
1 x Lipo Silicone Pad
1x DJI FPV Unit Fixed
1x Antenna Mount
1x RX Antenna Mount
