Product Name	FEICHAO Mini DC CH340G Atmega328P Microcontroller Controller Board Nano V 3.0 Driver Module Micro USB 3.3V-12V
Item NO.	F33489/F33490
Weight	0.055 kg = 0.1213 lb = 1.9401 oz
Category	FPV Drone and Part > RC Parts
Brand	FEICHAO
Creation Time	2020-10-14

product description:
color: blue
specification:
Weight: 20g
Size: 45*15mm

Features:

Nano is a very small Simple I/O platform with base and open source code. Compared with the previous USB version. Diecimila, Nano has a large advantage in volume, which can be used to develop DU run, and has Interactive electronic products; can also be used to develop interactive works that are connected to a computer and work with Flash, Processing, Max/Msp, PD, VVVV and other software.
This module modifies Ft232RL to CH340G for Windows 8, Windows 8.1, Windows 10 systems. For Windows 7 and above systems, the system can automatically search for drivers without network downloading.

technical parameter:
1. 12 digital input/output ports D2-D13.
2. 8 analog input ports A0-A7.
3. 1 pair of TTL level serial port transceiver port RX/TX.
4. 6 PWM ports, D3, D5, D6, D9, D10, D11.
5. Use Atmel Atmega328P-AU microcontroller.
6. Support USB download and power supply.
7. Support external 3.3V-12V DC power supply.
8. Support lithium battery and 9V battery power supply.
9. Support ISP download.

The product contains:
Nano(CH340G) Controller Board * 1
