Product parameters
MAK 7-inch product specifications
Maximum propeller: 7 inches
WHEELBASE: 295MM
SIZE: 193*223MM
Weight: 128g
BOTTOM PLATE THICKNESS: 2.5MM
TOP PLATE THICKNESS: 2.5MM
SPLINT THICKNESS: 2MM
ARM THICKNESS: 5MM
PROTECTIVE FRAME THICKNESS: 2MM
Recommend parts
Recommended Specifications (not included)
Flight controller: F4 F722
ESC: 40A~65A
Motor: 2806 2806.5 2807
Propeller: 7040 7035 (7 inches)
Battery: 5S 2200mAh~6S5200mAh
Camera: CADDX Foxeer II Razer
Features of the MAK 4 series products:
1. MAK 4 fancy rack, lighter and better performance for more convenient installation.
2. Smooth flight, FPV shooting is easier and more elegant.
3. The H-shaped structure does not affect the flight experience at all, but compared with the X-shaped structure, the arm is shorter, lighter in weight, and the arm strength is higher
4. The layout of the H-type has more installation space in the middle section of the cabin, the center of gravity is also lower, and the flight is more stable.
5. THE MOUNTING SIZE OF THE FPV LENS IS 19MM WIDTH, WHICH IS SUITABLE FOR MICRO LENSES, SUCH AS THE FLATHEAD BROTHER II RAZER MICRO/TOOTHLESS MICRO
6. At the same time, the front and rear of the cabin are reserved for flight control installation positions with two hole spacings of 30.5*30.5 and 20*20, which are suitable for the installation of various flight control equipment.
7. FIXED MOTOR MOUNTING HOLE SPACING: 16*16/16*19/19*19MM ARE COMPATIBLE to ensure the strength of the frame.
8. The corners of the whole machine are chamfered, the workmanship is fine, the structure is reasonable, and of course, there are customized thickened aluminum tubes to ensure the strength of the frame.
